Band Pass Filter Micro-4202-C6
Band Pass Filter Micro-4202-C6
The Band Pass Filter Micro-4202-C6 consists of 6 quarter wavelength cavities. The housing is made of extruded aluminium, the chassis of galvanized steel. The filter is black coated prevent corrosion. Narrow pass band range with low insertion loss, high stop band attenuation.
It can be used:
- To improve the input selectivity of receivers and amplifiers
- To increase the isolation of transmitters, whose re-spective antennas are mounted close together
- To suppress noise sidebands and intermodulation products.
| Electrical | Micro-4202-C6 |
|---|---|
| Frequency range, MHz | 400-470 |
| Band pass, MHz | 4-10 |
| Power input (max), W | 150 |
| Insertion loss, dB | < 2 |
| Impedance, Ohms | 50 |
| VSWR | > 18 (< 1.3) |
| Mechanical | |
| Connectors | N-female |
| Temperature range, °C | -30...+60 |
| Dimensions (LxWxH), mm | 201 x 150 x 110 |
| Net weight lb. (kg) | 5.3 (2.4) |
